Electric pallet stacker Linde L10B 2010,№752

Capacity (kg)

1000

Forks lifting height (mm)

2400

Forks length (mm)

1150

Number: 3862

Electric pallet stacker Linde L10B 2010,№752

Name: Electric pallet stacker Linde L10B 2010,№752
Brand: linde
SKU: 3862
Availability: SoldOut

Not available

Price on application

Order

Brand: Linde (Germany)

Description:

Linde L10B is an electric stacker with rated capacity - 1000 kg and lifting height up to 2400 mm. Has Sinergo interface. Tiller of the stacker effectively protects the operator's hands while its length and low mount ensure a safe distance between operator and chassis. AC motor in combination with Linde LAC digital control system provides high efficiency, and the OptiLift mast function control system provides proportional carriage lifting / lowering control.

Cash payments

Card payments

Key features Electric pallet stacker Linde L10B 2010,№752

Model	Linde L10B
Year of manufacture	2010
Engine hours (m/h.)	3942
Capacity (kg)	1000
Forks lifting height (mm)	2400
Overall height with lowered mast (mm)	1700
Overall length (mm)	1800
Overall width (mm)	800
Forks length (mm)	1150
Battery voltage,capacity (V/Ah)	24/180
Drive motor rating (kW)	1.2
Lift motor rating (kW)	2.2
Ground clearance (mm)	30
Turning radius (mm)	1460
Aisle width for pallets (mm)	2150
Maximum speed (km/h)	6
Forks lifting speed laden/ unladen (mm/s)	90/200
Forks lowering speed laden/ unladen (mm/s)	230/230
Overall weight (kg)	1130
